Torque Screwdriver Torc-Tech TW262-06
- Model code TW262-06
- Torque range 2.0 – 10 Nm
- Torque accurancy ±6%
- Drive 1/4” female hexagon
- Dual scale: N.m or lbf.in
- Torque setting resolution 0.1 N.m
- ISO 6789-1:2017 certified
- Torque adjustable and locking system
- Weight: 0.3 kg, tool length: 195 mm
- House calibration certificate included
- Accredited calibration available on option
- Made in Taiwan, manufacturer: Torc-Tech
- Technical support provided by Surkon
|
|
Torc-Tech TW Torque Screwdriver |
10 Nm Adjustable Torque Screwdriver
| Part No | Model No | Torque Ranges | Torque Range | Scale |
| # | # | (N.m) | (cN.m) | (Nm) |
| TW260-02 | TTS-201 | 0.1 - 1.2 | 10 - 120 | 0.01 |
| TW260-17 | TTS-206 | 0.4 - 2.6 | 40 - 260 | 0.02 |
| TW262-04 | TTS-202 | 1.0 - 3.5 | 100 - 350 | 0.05 |
| TW262-02 | TTS-203 | 1.0 - 6.0 | 100 - 600 | 0.1 |
| TW262-03 | TTS-204 | 4.0 - 9.0 | 400 - 900 | 0.1 |
| TW262-05 | TTS-205 | 5.0 - 10 | 500 - 1000 | 0.1 |
| TW262-06 | TTS-208 | 2.0 - 10 | 200 - 1000 | 0.1 |
| Part No | Length | Weight |
| # | (mm) | (kg) |
| TW260-02 | 180 | 0.230 |
| TW260-17 | 180 | 0.230 |
| TW262-04 | 195 | 0.340 |
| TW262-02 | 195 | 0.340 |
| TW262-03 | 195 | 0.340 |
| TW262-05 | 195 | 0.340 |
| TW262-06 | 195 | 0.340 |
 |
 |
 |
 |
